Replace OAuth2RestTemplate with RestClient: A Modern Spring Boot API Client

· 11 min read

Replace OAuth2RestTemplate with RestClient: A Modern Spring Boot API Client

In the previous post, we built a program that walks an Order API (buyers, suppliers, customer numbers, articles) and places a test order. It works, but it’s built on OAuth2RestTemplate, and that class has no future. In this post we rebuild the same client with Spring’s modern RestClient, without changing a single line of the search logic.

What Changed, and Why It Matters

  • OAuth2RestTemplate is deprecated. It belongs to the old Spring Security OAuth project, which Spring no longer maintains. OAuth2 client support now lives inside Spring Security itself.
  • The password grant is gone. Spring Security 7.0 removed support for it, because it forces the client application to handle the user’s password. The recommended flows are client credentials (machine to machine) and authorization code (on behalf of a user).
  • RestClient is the modern HTTP client. Introduced in Spring Framework 6.1 (Spring Boot 3.2), it has a fluent API like WebClient, but it is synchronous like RestTemplate.

Our Order API still only offers the password flow. That’s common in B2B systems: you can’t change the authorization server on your own schedule. So we migrate in two steps:

  1. Today: drop the deprecated library and keep the existing server.
  2. Later: switch to client credentials once the server supports it.

Part 1: RestClient with the Existing Token Endpoint

The only dependency is the Spring Boot web starter, which brings RestClient and Jackson:

1
2
3
4

<dependency>
  <groupId>org.springframework.boot</groupId>
  <artifactId>spring-boot-starter-web</artifactId>
</dependency>

The client gets an access token once, then sends it as a Bearer header on every request:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75

public class SellyApiClient {

  private final RestClient restClient;

  public SellyApiClient(String baseUrl, String tokenUrl,
                        String clientId, String clientSecret,
                        String username, String password) {
    String accessToken = fetchAccessToken(tokenUrl, clientId, clientSecret, username, password);
    this.restClient = RestClient.builder()
        .baseUrl(baseUrl)
        .defaultHeader(HttpHeaders.AUTHORIZATION, "Bearer " + accessToken)
        .build();
  }

  private static String fetchAccessToken(String tokenUrl, String clientId, String clientSecret,
                                         String username, String password) {
    MultiValueMap<String, String> form = new LinkedMultiValueMap<>();
    form.add("grant_type", "password");
    form.add("username", username);
    form.add("password", password);

    TokenResponse token = RestClient.create()
        .post()
        .uri(tokenUrl)
        .headers(headers -> headers.setBasicAuth(clientId, clientSecret))
        .contentType(MediaType.APPLICATION_FORM_URLENCODED)
        .body(form)
        .retrieve()
        .body(TokenResponse.class);

    return token.accessToken();
  }

  public List<Buyer> getBuyers() {
    return restClient.get()
        .uri("/api/v2/buyers")
        .retrieve()
        .body(new ParameterizedTypeReference<List<Buyer>>() {});
  }

  public List<Supplier> getSuppliers(Buyer buyer) {
    return restClient.get()
        .uri("/api/v2/suppliers?buyerId={buyerId}", buyer.getBuyerId())
        .retrieve()
        .body(new ParameterizedTypeReference<List<Supplier>>() {});
  }

  public List<CustomerNumber> getCustomerNumbers(Buyer buyer, Supplier supplier) {
    return restClient.get()
        .uri("/api/v2/customerNumbers?buyerId={buyerId}&supplierId={supplierId}",
            buyer.getBuyerId(), supplier.getSupplierId())
        .retrieve()
        .body(new ParameterizedTypeReference<List<CustomerNumber>>() {});
  }

  public List<Article> getArticles(Buyer buyer, Supplier supplier, CustomerNumber customerNumber) {
    return restClient.get()
        .uri("/api/v2/articles?buyerId={buyerId}&supplierId={supplierId}&customerNumberId={customerNumberId}",
            buyer.getBuyerId(), supplier.getSupplierId(), customerNumber.getCustomerNumberId())
        .retrieve()
        .body(new ParameterizedTypeReference<List<Article>>() {});
  }

  public Order createOrder(Order order) {
    return restClient.post()
        .uri("/api/v2/orders")
        .contentType(MediaType.APPLICATION_JSON)
        .body(order)
        .retrieve()
        .body(Order.class);
  }

  record TokenResponse(@JsonProperty("access_token") String accessToken,
                       @JsonProperty("expires_in") long expiresIn) {}
}

What each piece does:

  • fetchAccessToken sends the same request OAuth2RestTemplate sent behind the scenes: a form POST to /oauth/token with grant_type=password, authenticated with the client ID and secret as HTTP Basic credentials.
  • TokenResponse is a Java record that maps the two fields we need from the token response JSON.
  • defaultHeader adds Authorization: Bearer … to every request made by this RestClient, so the API methods don’t repeat it.
  • uri("…?buyerId={buyerId}", buyer.getBuyerId()) fills in URI variables and encodes them correctly, instead of concatenating strings.
  • retrieve().body(…) converts the JSON response into Java objects. For lists we pass a ParameterizedTypeReference, just as before.

retrieve() throws a RestClientResponseException for 4xx and 5xx responses, so errors don’t fail silently. The token is fetched once; that is fine for a test program that runs in seconds. A long-running service has to renew it before it expires, and Part 2 handles that automatically.

Swapping a deprecated library without touching the business logic is exactly what good design buys you. That idea runs through every chapter of this book:

codersite

The Search Logic Doesn’t Change

This is the labeled-break version from the previous post, now calling SellyApiClient:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

public final class CreateOrderRandomTest {

  private static final Logger logger = LoggerFactory.getLogger(CreateOrderRandomTest.class);

  public static void main(String[] args) {
    SellyApiClient api = new SellyApiClient(
        "http://localhost:41231/cloud",
        "http://localhost:41231/cloud/oauth/token",
        System.getenv("API_CLIENT_ID"),
        System.getenv("API_CLIENT_SECRET"),
        System.getenv("API_USERNAME"),
        System.getenv("API_PASSWORD"));

    search:
    for (Buyer buyer : api.getBuyers()) {
      for (Supplier supplier : api.getSuppliers(buyer)) {
        for (CustomerNumber customerNumber : api.getCustomerNumbers(buyer, supplier)) {
          List<Article> articles = api.getArticles(buyer, supplier, customerNumber);
          if (articles.isEmpty())
            continue;
          Order order = api.createOrder(buildOrder(buyer, supplier, customerNumber, articles.get(0)));
          logger.info("Order {} created for buyerId={}, supplierId={}, customerNumberId={}",
              order.getOrderId(), buyer.getBuyerId(), supplier.getSupplierId(),
              customerNumber.getCustomerNumberId());
          break search;
        }
      }
    }
  }

  //buildOrder(...) as in the previous post
}

All the HTTP and security details live in one class, and the program reads like the business process it automates.

Part 2: Client Credentials with Spring Security

The password flow is the part that still has to go. Once your authorization server supports the client credentials flow, Spring Security can fetch, cache and renew tokens for you. Add the OAuth2 client starter:

1
2
3
4

<dependency>
  <groupId>org.springframework.boot</groupId>
  <artifactId>spring-boot-starter-oauth2-client</artifactId>
</dependency>

Register the client in application.yml. The credentials come from environment variables:

1
2
3
4
5
6
7
8
9
10
11
12
13
14

spring:
  security:
    oauth2:
      client:
        registration:
          selly:
            provider: selly
            client-id: ${API_CLIENT_ID}
            client-secret: ${API_CLIENT_SECRET}
            authorization-grant-type: client_credentials
            scope: read,write
        provider:
          selly:
            token-uri: http://localhost:41231/cloud/oauth/token

Then build a RestClient with Spring Security’s OAuth2ClientHttpRequestInterceptor. Because a test program or a scheduled job has no web request, we use AuthorizedClientServiceOAuth2AuthorizedClientManager:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33

@Configuration
public class SellyClientConfig {

  @Bean
  public OAuth2AuthorizedClientManager authorizedClientManager(
      ClientRegistrationRepository clientRegistrationRepository,
      OAuth2AuthorizedClientService authorizedClientService) {

    OAuth2AuthorizedClientProvider authorizedClientProvider =
        OAuth2AuthorizedClientProviderBuilder.builder()
            .clientCredentials()
            .build();

    AuthorizedClientServiceOAuth2AuthorizedClientManager authorizedClientManager =
        new AuthorizedClientServiceOAuth2AuthorizedClientManager(
            clientRegistrationRepository, authorizedClientService);
    authorizedClientManager.setAuthorizedClientProvider(authorizedClientProvider);

    return authorizedClientManager;
  }

  @Bean
  public RestClient sellyRestClient(OAuth2AuthorizedClientManager authorizedClientManager) {
    OAuth2ClientHttpRequestInterceptor interceptor =
        new OAuth2ClientHttpRequestInterceptor(authorizedClientManager);
    interceptor.setClientRegistrationIdResolver(request -> "selly");

    return RestClient.builder()
        .baseUrl("http://localhost:41231/cloud")
        .requestInterceptor(interceptor)
        .build();
  }
}
  • authorizedClientManager knows how to obtain a token for the selly registration with the client credentials flow, and keeps it until it expires.
  • OAuth2ClientHttpRequestInterceptor asks the manager for a valid token before each request and adds the Authorization header.
  • setClientRegistrationIdResolver(request -> "selly") tells the interceptor which registration to use for every call made by this RestClient.

SellyApiClient now receives this RestClient in its constructor instead of fetching a token itself. The fetchAccessToken method disappears, and the search loop still doesn’t change.

Before and After

  2024 version Part 1 Part 2
HTTP client OAuth2RestTemplate (deprecated) RestClient RestClient
OAuth2 flow Password Password Client credentials
Token handling Library Fetched once by our code Spring Security, renewed automatically
Needs a server change No No Yes
Business logic Nested loops + flags Labeled break Labeled break


Further reading: Spring Security: Authorized Client features and What’s new in Spring Security 7.0.

Migrations like this one come up in interviews too: why a library was deprecated, what replaces it, and how to change it without breaking anything. Prepare with real questions:
